2 Core Round Screened Audio Cable

Cat No:
WB1504
Sold as:Roll (100 Metre)
Carton size:400
In Stock

$0.98

Description

Light duty round audio signal cable. Includes two conductors for stereo audio signal or similar with a single outer screen. Single screen for common ground connection with grey PVC insulation.

Specifications

Wire Category
Figure 8 / composite
Retail Sales Unit
Metre
Roll Length
100m
AWG
28
Cross Sectional Area
0.08mm²
Conductor Overall Diameter
0.32mm
Individual Conductor Strand Diameter
0.12mm
Number of Conductor Strands
7pc
Resistance per Linear Metre
0.2245mΩ
Colour
Light Grey
Wire Category
Round Screened
AWG
28
Conductor Overall Diameter
0.32mm
Number of Conductor Strand
7
Individual Conductor Strand Diameter
0.12mm
Resistance Per Linear Metre
0.2245Ω
Retail Sales Unit
Metre
Roll Length
100m
Cross Sectional Area
0.08mm²
Colour
Grey
Cable length
100m
Packaged Dimensions
100 x 0.4 x 0.4 cm
