30W 12V 2.5A Mini Power Supply
- Cat No:
- MP3302
- MPN:
- IRM-30-12ST
$51.95
Description
The IRM Series is a miniature encapsulated AC/DC power supply. This on board module features compact size and extremely low (<0.1W) no load power consumption at standby mode. This allows designers to easily conform to the requirements of ErP norm (Energy-related Products) and EISA. The 94V-0 flame retardant plastic case and fully-potted silicone enhance the heat dissipation and meet anti-vibration demand up to 5G. The new series complies with UL/CUL/TUV/CB/CE certificates for safety. Suitable applications include electronic instruments, hand held electronics, factory automation and electrical or mechanical equipment. Our range comes with screw terminals.
• Universal AC input / Full range
• Compact size
• Protections: Short circuit / Overload / Over voltage
• Cooling by free air convection
• Isolation Class II
• No load power consumption <0.1W
• Pass LPS
• 100% full load burn-on test
• High reliability
Specifications
- Length
- 90.0mm
- Width
- 40.0mm
- Height
- 30.0mm
- Weight
- 110.0g
- Packaged Dimensions
- 10.0cm(Length) x 4.7cm(Width) x 3.5cm(Height)
