Blue 5mm LED 13500mcd Round Clear

Cat No:
ZD0183
Sold as:1 Each
Carton size:2000
In Stock

$2.45

Description

Blue LED 5mm Clear 13500MCD

Specifications

LED Type
5mm Standard LED
Illumination Type
Single Colour
Light Colour
Blue
Light Wavelength
470.0nm,470.0nm
Lens Type
waterclear
Viewing Angle
20.0°
Intensity
13500.0mcd
V<sub>f (typ)</sub> - Typical Forward Voltage
3.2V
I<sub>f (typ)</sub> - Typical Forward Current
30.0mA
I<sub>f (max)</sub> - Maximum Forward Current
100.0mA
Resistor for 5VDC
56.0Ω
Resistor for 9VDC
180.0Ω
Resistor for 12VDC
270.0Ω
active mount type
Through Hole
active connector type
Solder Legs
component package
radial
active number of legs
2.0 count
Diameter
5.0mm
Packaged Dimensions
0.5cm(Length) x 0.5cm(Width) x 3.5cm(Height)
