Red 3mm LED 40mcd Round Diffused
- Cat No:
- ZD0100
In Stock
$0.30
Description
Red 3mm LED round diffused.
Specifications
- LED Type
- 3mm Standard LED
- Illumination Type
- Single Colour
- Light Colour
- Red
- Lens Type
- Diffused
- Light Wavelength
- 650.0nm
- V<sub>f (typ)</sub> - Typical Forward Voltage
- 2.3V
- I<sub>f (typ)</sub> - Typical Forward Current
- 15.0mA
- I<sub>f (max)</sub> - Maximum Forward Current
- 15.0mA
- Intensity
- 40.0mcd
- Viewing Angle
- 45.0°
- Resistor for 5VDC
- 180.0Ω
- Resistor for 9VDC
- 470.0Ω
- Resistor for 12VDC
- 680.0Ω
- active connector type
- Solder Legs
- Diameter
- 3.0mm
- Packaged Dimensions
- 3.5cm(Length) x 0.35cm(Width) x 0.35cm(Height)
