Red 5mm LED 3800mcd Round Clear
- Cat No:
- ZD0154
In Stock
$1.25
Description
Red 5mm LED 3800mCd Round Clear
Specifications
- LED Type
- 5mm Standard LED
- Illumination Type
- Single Colour
- Light Colour
- Red
- Light Wavelength
- 625.0nm
- Lens Type
- waterclear
- Viewing Angle
- 15.0°
- Intensity
- 4000.0mcd
- V<sub>f (typ)</sub> - Typical Forward Voltage
- 2.0V
- I<sub>f (typ)</sub> - Typical Forward Current
- 20.0mA
- I<sub>f (max)</sub> - Maximum Forward Current
- 50.0mA
- Resistor for 5VDC
- 150.0Ω
- Resistor for 9VDC
- 360.0Ω
- Resistor for 12VDC
- 510.0Ω
- Diameter
- 5.0mm
- Packaged Dimensions
- 3.5cm(Length) x 0.5cm(Width) x 0.6cm(Height)
