SPST LED Illuminated - Paddle Switch
- Cat No:
- SK0964
Sold as:1 Each
In Stock$5.95
Description
Paddle type actuator with built in red LED.
Features:
- Mounts easy in a 20mm hole.
- 6 amps @ 250VAC
- LED requires 12V @ 20mA
- Black body
- Q.C. tab termination
- Solder tabs for LED
Specifications
- Switch Type
- Rocker
- Switch Function
- Locking On/Off
- Switch Connection
- Spade Terminals
- Switch Colour Coded
- Black
- Mechanism Material
- Plastic
- AC Voltage rating
- 250.0V
- AC current rating
- 10.0A
- Nominal Voltage
- 12.0V-12.0V
- Type
- Rectangular LED
- Illumination Colour
- Red
- Connection
- Solder Tags
- Illumination Position
- Top
- Packaged Dimensions
- 3.5cm(Length) x 2.5cm(Width) x 2.5cm(Height)
